Fluorescent Emergency Ballasts
l
For normal and emergency operation of fluorescent lamps, no need an extra electronic ballast
l
Normal and emergency mode conversion within 0.3 seconds
l
Built-in battery pack replaceable
l
Aluminum housing
184009
44W, 120-277VAC
|
Type |
184009 |
|
Lamp type |
T8 2x17W, 2x18W, 1x17W, 1x18W, 1x32W,
1x36W |
|
Rated voltage |
120-277VAC 50/60Hz |
|
Rated current |
0.44A |
|
Rated power |
44W |
|
Operation frequency |
320kHz ≥ f ≥ 50kHz |
|
Power factor |
>0.9 |
|
Battery |
Ni-Cd |
|
Charging time |
24 Hours |
|
Discharge time |
>90 minutes |
|
Charging current |
0.13A (Max.) |
|
Life time |
5 years |
|
Charging cycles |
>500 |
|
Operation temperature |
0-50℃ (32°F-122°F) |
|
Initial lumen output |
500LM |
|
Efficiency |
70% |
|
Wire |
Over load, over current, inrush, over
voltage, charging and discharging, open circuit , short circuit protection
with auto reset |
|
Abnormal protection |
0.75-1.5mm2 |
|
EMC&
FCC IC standard |
EN 55015, EN
61547, EN 61000-3-2, EN 61000-3-3, FCC part 18; ICES-005 |
|
Safety standard |
EN
61347-1, EN 61347-2-7, UL924, CSA C.22.2 No. 141 |
|
Meas. Module mm [inch] |
L250
[9.84] x W65 [2.56] x H28.5 [1.12] Mounting
Center: 242 [9.53] |
