Emergency LED Driver for UFO High Bay
l
Emergency operation of LED light source and luminaires, for both factory and field installation
l
Perfectly compatible with non dimmable LED UFO, High Bay luminaires
l
Constant emergency power output, wide range of output voltage from 10 to 300VDC, output current auto adjustable
l
Auto test function reduces the maintenance cost
l
IP67 rating. Suitable for outdoor and wet applications
184901-1-UFO
9W, 10-300VDC
|
Type |
184901-1-HB |
|
Lamp
type |
LED
High-bay or UFO luminaire |
|
Rated
voltage |
120-277VAC
50/60Hz |
|
Rated
current |
0.04A |
|
Rated
power |
3W |
|
Emergency
output power |
9W |
|
Output
voltage |
10-300VDC |
|
Output
current of AC driver |
3A
(Max.) |
|
Operation
frequency |
320kHz≥f≥50kHz |
|
Power
factor |
0.5 |
|
Battery |
Li-ion |
|
Charging
time |
24
Hours |
|
Discharge
time |
>90
Minutes |
|
Life
time |
5
Years |
|
Charging
current |
0.17A |
|
Charging
cycles |
>1000 |
|
Operation
temperature |
0-50℃ (32°F-122°F) |
|
Efficiency |
80% |
|
Abnormal
protection |
Over load, over current, inrush, over voltage, over temperature, charging and discharging, open circuit , short circuit protection with auto reset |
|
Wire |
0.75-1.5mm2 |
|
EMC& FCC IC standard |
EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3; FCC
part 15; ICES-005 |
|
Safety standard |
EN 61347-1, EN 61347-2-7, UL924, CSA C.22.2 No. 141 |
|
Meas.
mm [inch] |
L441.2 [13.37] x W40 [1.57] x H40 [1.57] |
