IP67 Waterproof Light
l
Up and down beam directions with high lumen output with low UGR
l
Same lumen output in both normal and emergency modes
l
C5M Anti-corrosion, IEC 60721-3-3 3M5 vibration resistant
l
IP68 quick connectors allow a fast wiring connection without needing open the lights
l
Battery can be easily tested and disconnected by pressing the exposed LED test switch on the endcap
l
Automatic testing to minimize maintenance cost after installation
l
Ideal for ladders' illumination in onshore and offshore windmills
LL18H08
8W, 100-277VAC
LL18J10
8W (10W Charging) (20W Charging + Heating), 100-277VAC
|
Product name |
SPR LADDER ST |
SPR LADDER EH |
|
Item No. |
LL18H08 |
LL18J10 |
|
Description |
Light, LED, Standard, SW/CW |
Light, LED, Emergency backup, SW/CW |
|
Input voltage |
100-277VAC 50/60Hz |
|
|
Input power |
8W |
8W |
|
10W (Charging) |
||
|
20W (Charging + Heating) |
||
|
Nominal current |
0.08A |
0.08A |
|
0.10A |
||
|
0.20A |
||
|
Operation temp. |
-40~55°C |
|
|
Survival temp. |
-45~60°C |
|
|
Lamp type |
LED SMD, 4000-6000K |
|
|
Normal lumen output |
900LM |
900LM |
|
Emergency lumen output |
N/A |
900LM |
|
Emergency time |
N/A |
90 Minutes |
|
Expected battery life |
N/A |
7-10 Years |
|
Battery full charge |
N/A |
24 Hours |
|
Meas. mm |
L200 x W150 x H66, Mounting center: 192 / 100 |
L200 x W150 x H66, Mounting center: 192 / 100 |
